MODBUS VARIABLES
Magnitude Symbol Instant Maximum
Minimu
m
Unit
Active Energy
kW·h III
3C-3D 9C-CD FC-FD w·h
Inductive Reactive Energy
kvarL·h III
3E-3F 9E-9F FE-FF w·h
React. Energy Capacitive
kvarC·h III
40-41 A0-A1 100-101
w·h
Apparent Energy
kVA·h III
56-57 B6-B7 116-117
w·h
Active energy Generated
kW·h III (-)
58-59 B8-B9 118-119
w·h
Inductive energy generated
kvarL·h III (-)
5A-5B BA-BB 11A-11B
w·h
Capacit. Energy Generated
kvarC·h III (-)
5C-5D BC-BD 11C-11D w·h
Apparent Energy Generated
kVA·h III (-)
5E-5F BE-BF 11E-11F w·h
*Recordings available in HAR model
MODBUS VARIABLES
Magnitude Symbol L1 L2 L3 Unit
Harmonic decomposition in VOLTAGE Instant
RMS Current
V
2AE-2AF 2CC-2CD 2EA-2EB Vx10
Harmonic 2 2B0-2B1 2CE-2CF 2EC-2ED
%
Harmonic 3
2B2-2B3 2D0-2D1 2EE-2EF
%
Harmonic 4
2B4-2B5 2D2-2D3 2F0-2F1
%
Harmonic 5
2B6-2B7 2D4-2D5 2F2-2F3
%
Harmonic 6
2B8-2B9 2D6-2D7 2F4-2F5
%
Harmonic 7 2BA-2BB 2D8-2D9 2F6-2F7
%
Harmonic 8 2BC-2BD 2DA-2DB 2F8-2F9
%
Harmonic 9
2BE-2BF 2DC-2DD 2FA-2FB
%
Harmonic 10 2C0-2C1 2DE-2DF 2FC-2FD
%
Harmonic 11 2C2-2C3 2E0-2E1 2FE-2FF
%
Harmonic 12 2C4-2C5 2E2-2E3 300-301
%
Harmonic 13 2C6-2C7 2E4-2E5 302-303
%
Harmonic 14 2C8-2C9 2E6-2E7 304-305
%
Harmonic 15 CA-CB 2E8-2E9 306-307
%
Harmonic decomposition in CURRENT Instant
RMS current
A
1F4-1F5 212-213 230-231 mA
Harmonic 2 1F6-1F7 214-215 232-233
%
Harmonic 3
1F8-1F9 216-217 234-235
%
Harmonic 4
1FA-1FB 218-219 236-237
%
Harmonic 5
1FC-1FD 21A-21B 238-239
%
Harmonic 6
1FE-1FF 21C-21D 23A-23B
%
Harmonic 7 200-201 21E-21F 23C-23D
%
Harmonic 8 202-203 220-221 23E-23F
%
Harmonic 9
204-205 222-223 240-241
%
Harmonic 10 206-207 224-225 242-243
%
Harmonic 11 208-209 226-227 244-245
%
Harmonic 12 20A-20B 228-229 246-247
%
Harmonic 13 20C-20D 22A-22B 248-249
%
Harmonic 14 20E-20F 22C-22D 24A-24B
%
Harmonic 15 210-211 22E-22F 24C-24D
%
