CVM-NRG96
Mn_cvm-nrg_03.doc
Installation and start-up
This manual contains information and warnings that must be followed by the user to
ensure the safe operation of the equipment and to maintain it in a safe condition. The
analyzer must not be switched on until it is finally attached to the electrical board.
IF THE EQUIPMENT IS HANDLED IN A WAY NOT SPECIFIED BY THE
MANUFACTURER, THE EQUIPMENT'S PROTECTION MAY BE COMPROMISED
When it is likely that the equipment has lost its protection (with visible damage), it
must be disconnected from the auxiliary supply. In this event, contact a qualified
technical service representative.
Installing the equipment
Check the following points before switching the equipment on:
a) Power supply voltage.
b) Maximum voltage in the measurement circuit.
c) Maximum admissible current.
d) Features of the transistor (digital output).
e) Operating conditions.
f) Safety.
A. Power supply voltage
Standard version:
- Power supply : 230 V AC.
- Frequency : 50-60 Hz
- Power supply tolerance : -15% / +10%
- Connection board : Terminals 1-2 (Power Supply)
- Consumption of the equipment : 5 V·A
Version Plus:
- Power supply : 85…265 V AC. // 95…300 V DC.
- Frequency : 50-60 Hz
- Connection board : Terminals 1-2 (Power Supply)
- Consumption of the equipment : 5 V·A
