CVM-NRG96
Mn_cvm-nrg_03.doc
To select one of the two display options, just press the MAX key and the two
options will alternate.
Once the required option is selected, press the
key to enter the data and
access the following setting step.
8. Digital output for the transistor.
The CVM-NRG96's digital output may set:
a. Pulse per n kW.h or kvar.h (Energy): the value for the energy
consumed or generated may be set to generate a pulse.
b. Alarm condition: associates a magnitude to a digital output, setting
a maximum, minimum and delay (delay) for the trip condition.
In the event that no variable needs to be set, put 00 and enter using the
key.
The display shows ”Out Uar Code”.
Ou t
Ua r
Co d e
00
Setting pulse per n kW·h or kvar·h
Energy code table:
Magnitude Symbol Code
Active Energy III
kW·h III
31
Inductive Reactive Energy III
KvarL·h III
32
Capacitive Reactive Energy III
KvarC·h III
33
Apparent Energy III
kVA·h III
44
Active energy Generated III
kW·h III (-)
45
Inductive Reactive Energy Generated III
KvarL·h III (-)
46
Capacitive Reactive Energy Generated III
KvarC·h III (-)
47
Apparent Energy Generated III
kVA·h III (-)
48
