CVM-NRG96
Mn_cvm-nrg_03.doc
3. Setting the Power Demand Meter
Magnitude to Integrate
The display shows “set pd Code” followed by two digits which identify the
code or variable to be integrated as Maximum Demand.
None 00
Three phase active power
kW III
16
Three phase apparent power
kV·A III
34
Three phase current
AIII
36
Current per phase
A1 - A2 - A3
A-Ph
The MAX key allows the selection of the Maximum Demand variable to be
integrated.
Once selected to access the next setting step, press
.
Integration Period
The display shows “set pd Per” followed by two digits which will identify the
period of integration for the selected magnitude.
Set
PD
PEr
15
To write or change the value of the integration period repeatedly press the
MAX key increasing the value of the digit which is flashing at the time.
When the required value is on the screen, move on to the following digit by
pressing MIN, to allow the remaining values to be changed.
When the last digit has been changed, press MIN to move back to the first
digit, allowing the previously set values to be changed again.
The integration period may vary between 1 to 60 minutes.
To enter the data and access the following setting step, press
.
