Circutor CVM-NRG96 User Manual

CVM-NRG96
Mn_cvm-nrg_03.doc
MODBUS© memory map
MODBUS VARIABLES
Magnitude Symbol Instant Maximum Minimum Unit
Voltage Phase
V L1
00-01 60-61 C0-C1 V x10
Current
A L1
02-03 62-63 C2-C3 mA
Active Power
kW L1
04-05 64-65 C4-C5 w
Reactive Power
Kvar L1
06-07 66-67 C6-C7
w
Power Factor
PF L1
08-09 68-69 C8-C9
x 100
Voltage Phase
V L2
0A-0B 6A-6B CA-CB
V x10
Current
A L2
0C-0D 6C-6D CC-CD
mA
Active Power
kW L2
0E-0F 6E-6F CE-CF w
Reactive Power
Kvar L2
10-11 70-71 D0-D1 w
Power Factor
PF L2
12-13 72-73 D2-D3 x 100
Voltage Phase
V L3
14-15 74-75 D4-D5
V x10
Current
A L3
16-17 76-77 D6-D7
mA
Active Power
kW L3
18-19 78-79 D8-D9 W
Reactive Power
Kvar L3
1A-1B 7A-7B DA-DB W
Power Factor
PF L3
1C-1D 7C-7D DC-DD x 100
Active Power III
kW III
1E-1F 7E-7F DE-DF w
Inductive Power III
KvarL III
20-21 80-81 E0-E1 w
Capacitive Power III
KvarC III
22-23 82-83 E2-E3 w
Cos φ III
Cos φ III
24-25 84-85 E4-E5
x 100
Power Factor III
PF III
26-27 86-87 E6-E7
x 100
Frequency
Hz
28-29 88-89 E8-E9
Hz x 10
Voltage Line L1-L2
V12
2A-2B 8A-8B EA-EB V x10
Voltage Line L2-L3
V23
2C-2D 8C-8D EC-ED V x10
Voltage Line L3-L1
V31
2E-2F 8E-8F EE-EF V x10
% THD V L1
%THD VL1
30-31 90-91 F0-F1
% x 10
% THD V L2
%THD VL2
32-33 92-93 F2-F3
% x 10
% THD V L3
%THD VL3
34-35 94-95 F4-F5 % x 10
% THD A L1
%THD AL1
36-37 96-97 F6-F7 % x 10
% THD A L2
%THD AL2
38-39 98-98 F8-F9 % x 10
% THD A L3
%THD AL3
3A-3B 9A-9B FA-FB
% x 10
Apparent Power III
KvaIII
42-43 A2-A3 102-103 w
Maximum Demand
Md (Pd)
44-45 A4-A5 104-105 w/VA/mA
Three Phase Current (average)
A_AVG
46-47 A6-A7 106-107
mA
Neutral Current
In
48-49 A8-A9 108-109
mA
Maximum Demand A2
Md (Pd)
52-53 B2-B3 112-113
mA
Maximum Demand A3
Md (Pd)
54-55 B4-B5 114-115
mA
