CVM-NRG96
Mn_cvm-nrg_03.doc
Preferred Magnitude of Energy
The display shows ”set def pa9e Ener” and the Active Energy symbol (kWh)
flashes.
SEt
dEF
PA9 E
Ener
By repeatedly pressing the MAX key the required energy magnitude is
selected. This may be:
Magnitude of Energy Direction Symbol
Active Energy Consumption
kW·h
Inductive Reactive Energy Consumption
kvarL·h
Capacitive Reactive Energy Consumption
kvarC·h
Apparent Energy Consumption
kVA·h
Active Energy Generation (-)
- kW·h
Inductive Reactive Energy Generation (-)
- kvarL·h
Capacitive Reactive Energy Generation (-)
- kvarC·h
Apparent Energy Generation (-)
- kVA·h
Once the energy has been selected press the
key to enter the data and
access the next setting step
5. Backlight (Backlit display).
Backlight timer
The display shows ”set disp off”.
SEt
dI sp
off
00
Indicates the screen protector time (in seconds), disconnecting the
Backlight.
