Circutor CVM-NRG96 User Manual

CVM-NRG96
Mn_cvm-nrg_03.doc
Magnitude Phase Symbol L1 Code
Simple Voltage L3
V 3
11
Current L3
A 3
12
Active Power L3
kW 3
13
Reactive Power L/C L3
KvarL/C 3
14
Power Factor L3
PF 3
15
% THD V L3
THD V3
27
% THD A L3
THD A3
30
Magnitude Symbol Code
Simple Voltages
V1 / V2 / V3
90
Currents
A1 / A2 / A3
91
Active Powers
kW1 / kW2 / kW3
92
Reactive Powers
Kvar1 / kvar2 / kvar3
93
Power Factors
PF1 / PF2 / PF3
94
Compound Voltages
V12 / V23 / V31
95
% THD V
Thd1 / Thd2 / Thd3 V
96
% THD I
Thd1 / Thd2 / Thd3 A
97
Magnitude Symbol Code Magnitude Symbol Code
Active Power III
kW III
16
cos three phase cos
19
Inductive Power III
kvarL III
17 Power Factor III
PF III
20
Capacitive Power III
kvarC III
18 Frequency
Hz
21
Active Energy
kW·h
31 L1- L2 Voltage
V 12
22
React. Energy Inductive
Kvarh·L
32 L2-L3 Voltage
V 23
23
React. Energy Capacit.
Kvarh·C
33 L3-L1 Voltage
V 31
24
Apparent Power III
kV·A III
34
Maximum Demand
Md (Pd)
35 Maximum Demand L1
Md (Pd)
35*
Current III
AIII
36 Maximum Demand L2
Md (Pd)
42*
Neutral Current
I
N
37 Maximum Demand L3
Md (Pd)
43*
* Variables only valid if the Maximum Demand for current has been set per phase.
There are also some variables which refer to the three phases at the same
time (Function OR). If one of these variables has been selected, the alarm
will go off when any of the three phases meet the preset conditions.
Magnitude Symbol Code
Simple Voltages
V1 / V2 / V3
90
Currents
A1 / A2 / A3
91
Active Powers
kW1 / kW2 / kW3
92
Reactive Powers
Kvar1 / kvar2 / kvar3
93
Power Factors
PF1 / PF2 / PF3
94
Compound Voltages
V12 / V23 / V31
95
% THD V
Thd1 / Thd2 / Thd3 V
96
% THD I
Thd1 / Thd2 / Thd3 A
97
