Appendix E Installing the Wall Mount for the Cisco Unified IP Phone 6901 and 6911

Installing a Wall Mount for the Cisco Unified IP Phone 6911

Figure E-8 Mounting the Wall Bracket

Level wall

bracket on wall

Mark mounting

holes through

bracket on wall

274936

C D

Insert anchors

into wall

Screw bracket

to wall using

Phillips head

screws
