Cisco 6901 Administration Guide

F-7
Cisco Unified IP Phone 6901 and 6911 Administration Guide for Cisco Unified Communications Manager 8.6 (SCCP and SIP)
OL-24582-01
Appendix F Cisco Unified IP Phone Non-Lockable Wall Mount
ADA Non-Lockable Wall Mount Kit for 6900 Series
Figure F-7 Tab Location
To remove the phone and mounting plate from the wall bracket, you must disengage these tabs.
Before You Begin
You require two screwdrivers or metal sticks.
Step 1 Push the screw drivers into the left and right holes in the phone mounting plate approximately 1 in. (2.5
cm).
Step 2 Press firmly inwards (towards the phone) to disengage the tabs, lift up on the phone to release the phone
from the wall bracket, and then pull the phone towards you.
The following figure shows how to disengage the tabs.
345759
