Cisco 7962G User Manual

An Overview of Your Phone
Cisco Unified IP Phone 7962G and 7942G for Cisco Unified Communications Manager 6.0 (SCCP and SIP) 9
Item Description For more information, see...
1
Programmable
buttons
Depending on configuration,
programmable buttons provide access to:
• Phone lines and intercom lines (line
buttons) and intercom lines
• Speed-dial numbers (speed-dial
buttons, including the BLF speed-dial
feature)
• Web-based services (for example, a
Personal Address Book button)
• Call features (for example, a Privacy,
Hold, or Transfer button)
Buttons illuminate to indicate status:
Green, steady—Active call or
two-way intercom call
Green, flashing—Held call
Amber, steady—Privacy in use,
one-way intercom call, DND
active, or logged into Hunt
Group
Amber, flashing—Incoming call
or reverting call
Red, steady—Remote line in use
(shared line or BLF status)
• Understanding Phone
Screen Features, page 11
• Basic Call Handling,
page 16
• Speed Dialing, page 31
• Using a Shared Line,
page 35
• Using BLF to Determine a
Line State, page 38
• Using BLF to Determine a
Line State, page 38
• Placing or Receiving
Intercom Calls, page 29
2
Phone screen Shows phone features. Understanding Phone Screen
Features, page 11
3
Footstand button Allows you to adjust the angle of the phone
base.
Adjusting the Footstand,
page 5
4
Messages button Auto-dials your voice message service
(varies by service).
Accessing Voice Messages,
page 54
5
Directories button Opens/closes the Directories menu. Use it
to access call logs and directories.
Using Call Logs, page 48
6
Help button Activates the Help menu. Accessing the Help System on
Your Phone, page 13

Cisco 7962G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Case material	ABS
Product color	Black, Grey
Wall mountable	Yes
Bluetooth	No
Security algorithms	128-bit AES, 802.1x RADIUS
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	2
Voice codecs	G.711, G.711a, G.722, G.729A, G.729ab, iLBC
Volume control	Digital
Display diagonal	5 \
Display resolution	320 x 222 pixels
Display number of colors	Monochrome
Caller ID	-
Lines quantity	- lines
Phonebook capacity	- entries
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	203.2 mm
Width	266.7 mm
Height	152.4 mm
Weight	1600 g
