The SMB module is a heavy unit, please proceed with caution.
Note
Procedure
Step 1 Using the handle on the top of the chassis, align the SMB and chassis slot.
Step 2 Slide the SMB into the slot until it stops.
Step 3 Simultaneously press the latch release button on the SMB ejector and pull the ejector lever away from the
chassis.
