Figure 6 Chassis Ground Lug Location on the Cisco ASR 1004 Router
Use the following procedure to attach the grounding lug to the chassis ground connector on your chassis:
Step 1 Use the wire stripper to strip one end of the AWG #6 wire approximately 0.75 inches (19.05 mm).
Step 2 Insert the AWG #6 wire into the wire receptacle on the grounding lug.
Step 3 Use the crimping tool to carefully crimp the wire receptacle around the wire; this step is required to ensure a proper
mechanical connection.
Step 4
Attach the grounding lug with the wire on the left to avoid having the grounding wire overlapping the power supply.
Figure 7 shows how to attach the grounding screws.
Figure 7 Attaching a Grounding Lug to the Cisco ASR 1004 Router Chassis Ground Connector
1
Chassis ground connector on the Cisco ASR 1004 Router
1
Chassis earth ground studs and lead wire
3
Earth ground connector on the chassis
2
Grounding screws
4
Earth ground symbol
