Cisco ASR 1004 Quick Start Guide

30
Perform Other Configuration Tasks
To make advanced configuration changes after you establish the basic startup configuration for your router, refer to the Cisco
ASR 1000 Series Aggregation Services Routers Software Configuration Guide and modular configuration and modular
command reference publications in the Cisco IOS software configuration documentation set that corresponds to the software
release installed on your Cisco hardware. These publications contain additional information on using the configure command,
such as information about the following tasks:
• Understanding Diagnostic Mode feature
• Understanding Command Modes
• Booting and rebooting the router
• Understanding software packages for the Cisco ASR 1000 Series Aggregation Services Routers
• Software Upgrades
7 After Installation
Follow the instructions in this section to replace components after installation. The following topics are covered in this section:
• Powering Off the Cisco ASR 1004 Router Safely, page 30
• Remove and Replace a Power Supply, page 31
• Remove the Shared Port Adapter, page 36
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Powering Off the Cisco ASR 1004 Router Safely
This section explains how to shut down the Cisco ASR 1004 Router. It is recommended that before turning off all power to the
chassis, you issue the reload command. This insures that the operating system cleans up all the file systems. Once the reload
operation is complete, then the Cisco ASR 1004 Router can be powered off safely.
To remove power from a Cisco ASR 1004 Router safely, follow this procedure and see the examples:
Step 1 Slip on the ESD-preventative wrist strap that was included in the accessory kit.
Step 2 Enter the reload command.
Step 3 Confirm the reload command:
Rmcp-4ru-1#reload
Proceed with reload? [confirm]
Aug 17 00:06:47.051 R0/0: %PMAN-5-EXITACTION: Process manager is exiting: prs exit with reload chassis
code
Step 4 After confirming the reload command, wait until the system bootstrap message displays before powering off the system.
System Bootstrap, Version 12.2(33r)XN2, RELEASE SOFTWARE (fc1)
Technical Support: tap://www.cisco.com/techsupport
Copyright (c) 2010 by cisco Systems, Inc.
Current image running: Boot ROM0
Last reset cause: LocalSoft
ASR1000-RP1 platform with 4194303 Kbytes of main memory
mcp-4ru-1-rp0-rommon 1>

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
