Step 1 Connect a console terminal to the console port and then boot the router. The system boots from flash memory. The
following information appears after about 30 seconds.
Note This is only an example of the output display; prompts may vary.
Step 2 The first sections of the configuration script appear only at an initial system startup. On subsequent uses of the setup
facility, the script begins with a System Configuration Dialog as shown below: When asked if you would like to enter
the initial configuration dialog, enter yes.
Would you like to enter the initial configuration dialog? [yes/no] yes
At any point you may enter a question mark '?' for help.
Use ctrl-c to abort configuration dialog at any prompt.
Default settings are in square brackets '[]'.
Basic management setup configures only enough connectivity for management of the system, extended setup
will ask you to configure each interface on the system.
--- System Configuration Dialog ---
Would you like to enter the initial configuration dialog? [yes/no]: y
At any point you may enter a question mark '?' for help.
Use ctrl-c to abort configuration dialog at any prompt.
Default settings are in square brackets '[]'.
Basic management setup configures only enough connectivity
for management of the system, extended setup will ask you
to configure each interface on the system
Would you like to enter basic management setup? [yes/no]: n
First, would you like to see the current interface summary? [yes]: y
Any interface listed with OK? value "NO" does not have a valid configuration
Interface IP-Address OK? Method Status Protocol
GigabitEthernet0/0/0 unassigned NO unset down down
GigabitEthernet0/0/1 unassigned NO unset down down
GigabitEthernet0/0/2 unassigned NO unset down down
GigabitEthernet0/0/3 unassigned NO unset down down
GigabitEthernet0 unassigned YES unset administratively down down
Configuring global parameters:
Enter host name [Router]:
The enable secret is a password used to protect access to
privileged EXEC and configuration modes. This password, after
entered, becomes encrypted in the configuration.
Enter enable secret: test
The enable password is used when you do not specify an
enable secret password, with some older software versions, and
some boot images.
Enter enable password: tests
The virtual terminal password is used to protect
access to the router over a network interface.
Enter virtual terminal password: test
Configure SNMP Network Management? [yes]: n
Configure IP? [yes]: y
Configure RIP routing? [no]:
Configure bridging? [no]:
