Remove and Then Replace a DC Power Supply
Because of the power supply redundancy, there is no need to power off the Cisco ASR 1004 Router before removing one of the
DC power supplies.
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit. Statement
1003
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning Installation of the equipment must comply with local and national electrical codes. Statement 1074
Step 1 Before servicing the power supply, switch the circuit breaker Off in your equipment area.
Step 2 Slip on the ESD-preventative wrist strap that was included in the accessory kit.
Step 3 Switch the power supply circuit breaker switch to Off (O).
Step 4 Locate the terminal block on the rear of the chassis on the power supply.
Step 5 Remove the terminal block plastic cover and then follow these steps:
a. Unscrew the negative cable Kepnut screw, washer, and ground lug, and remove the stud and lead wire.
b. Unscrew the positive cable Kepnut screw, washer, and ground lug, and remove the stud and lead wire.
c. Unscrew the earth ground Kepnut screw, washer, and ground lug and remove the stud and lead ground wire.
Step 6 Loosen the captive screws on the DC power supply.
Note Two power supplies must be installed in the chassis at all times to ensure sufficient cooling. The system fans are inside
the power supply units and must spin for cooling. Because all the system fans can be powered by one power supply, the
second power supply unit does not have to be powered on, but it must be installed.
Caution If you remove a power supply, the system can run for a maximum of five minutes before the system shuts down.
The fans and power elements are independent within the power supply. Therefore, it is not required that the
replacement power supply be energized within five minutes. The only requirement is that the power supply be
installed in the chassis, which energizes the fans and maintains proper system cooling.
Step 7 Grasping the power supply handles, pull the power supply from the chassis. When you remove the DC power supply,
you will see similar messages in the log report as shown in the section, Remove and Then Replace an AC Power Supply,
page 31.
Step 8 Replace the DC power supply within five minutes or the system will shutdown.
You have removed a DC power supply from the Cisco ASR 1004 Router and now must replace the DC power supply within
five minutes.
This section provides instructions for installing the DC power supply.
Caution Before you connect DC-input power, you must install the DC power ground leads to the DC power supply.

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
