Cisco ASR 9000 Series Aggregation Services Router Getting Started Guide
OL-28417-02
Chapter Configuring Additional Router Features
Configuration Limiting
------------------------------------------------------------
Lines of configuration 0 65536 131072
Policies 0 3500 5000
Compiled policies size (kB) 0
RP/0/RSP1/CPU0:router#
The following example shows how the rpl maximum command changes the currently configured line
and policy limits. The show rpl maximum command displays the new settings.
RP/0/RSP1/CPU0:router# configure
RP/0/RSP1/CPU0:router(config)# rpl maximum policies 4000
RP/0/RSP1/CPU0:router(config)# rpl maximum lines 80000
RP/0/RSP1/CPU0:router(config)# commit
RP/0/RSP1/CPU0:Apr 1 00:23:44.062 : config[65709]: %LIBTARCFG-6-COMMIT : Configuration
committed by user 'UNKNOWN'. Use 'show configuration commit changes 1000000010' to view
the changes.
RP/0/RSP1/CPU0:router(config)# exit
RP/0/RSP1/CPU0:Apr 1 00:23:47.781 : config[65709]: %SYS-5-CONFIG_I : Configured from
console by console
RP/0/RSP1/CPU0:router# show rpl maximum
Mon May 31 23:25:24.444 DST
Current Current Max
Total Limit Limit
------------------------------------------------------------
Lines of configuration 0 80000 131072
Policies 0 4000 5000
Compiled policies size (kB) 0
RP/0/RSP1/CPU0:router#
Platform-Independent Multicast Configuration Limits
Table 17 summarizes the maximum limits for multicast configuration, including the commands used to
display and change the limits. These limits are applicable to any platform.
Ta b l e 17 Multicast Configuration Limits and Commands
Feature Limit Description
Default
Maximum
Limit
Absolute
Maximum
Limit
Configuration Command
Show Current Settings
Command (EXEC Mode)
Internet Group Management Protocol (IGMP) Limits
Maximum number of
groups used by IGMP
and accepted by a router
50,000 75,000 maximum groups n
(router IGMP configuration mode)
show igmp summary
Maximum number of
groups for each interface
accepted by a router
25,000 40,000 maximum groups-per-interface n
(router IGMP interface configuration
mode)
show igmp summary
Multicast Source Discovery Protocol (MSDP) Limits
Maximum MSDP Source
Active (SA) entries
20,000 75,000 maximum external-sa n
(router MSDP configuration mode)
show msdp summary
