Chapter Bringing Up Cisco IOS XR Software on the Router
Verifying the System After Initial Boot
6. show environment
DETAILED STEPS
Command or Action Purpose
Step 1
show version
Example:
RP/0/RSP0/CPU0:router# show version
Displays information about the router, including image names,
uptime, and other system information.
Step 2
admin
Example:
RP/0/RSP0/CPU0:router# admin
Places the router in administration EXEC mode.
Step 3
show platform [node-id]
Example:
RP/0/RSP0/CPU0:router(admin)# show platform
Displays information about the status of cards and modules
installed in the router.
• A card module is also called a node. When a node is
working properly, the status of the node in the State column
is IOS
XR RUN. The status of the supported SPA interface
is OK.
• The show platform node-id command is used to display
information for a specific node. Replace node-id with a
node name from the show platform command Node
column.
Note To view the status of all the cards and modules, the
show platform command must be executed in
administration EXEC mode.
Step 4
exit
Example:
RP/0/RSP0/CPU0:router(admin)# exit
Exits the administration EXEC mode.
Step 5
show redundancy
Example:
RP/0/RSP0/CPU0:router# show redundancy
Displays the state of the primary (active) and standby (inactive)
RPs, including the ability of the standby to take control of the
system.
• If both RPs are working correctly, one node displays active
role, the Partner node row displays standby role, and the
Standby node row displays Ready.
Step 6
show environment
Example:
RP/0/RSP0/CPU0:router# show environment
Displays information about the hardware attributes and status.
