Figure 106: Removing a Switch Fabric Card from the Cisco ASR 9922 Router Chassis
Pivot the ejector levers
outward to unseat the
card from the backplane
connector.
cLoosen the captive
screws.
a
Slide the card out of the
chassis.
dPush in both ejector lever
release buttons.
b
