Figure 117: Installing the Cisco ASR 9910 Router Chassis in a 2-Post Seismic Rack
Use screw and brackets from 2 post rack mount
bracket kit.
1
Follow these steps to install the chassis in the equipment rack.
Procedure
Step 1 Using two people, lift the chassis into the rack using the side handles and grasping underneath the power
supply bays (see the figure below).
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
111
Unpacking and Installing the Chassis
Installing the Chassis in a 2-Post Rack
