Cisco ASR 9010

Figure 125: Installing the Cisco ASR 9910 Router Chassis in a 4-Post Rack
Use screws and four post
rack mount brackets from
four post rack mount
bracket kit for this
installation.
2Use screws to attach the
router chassis to the rack.
1
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
118
Unpacking and Installing the Chassis
Preparing the 19 Inch 45-RU Rack
