Cisco ASR 9010

Figure 171: RSP Card Ejector Lever Positions During Installation
Vertical red lines in the figure indicate a line fully parallel to the RSP card front panel.
Note
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
165
Installing Cards and Modules in the Chassis
Installing RSP Cards in the Chassis
