Cisco ASR 9010

Figure 173: RP Card Ejector Lever Positions During Installation
Vertical red lines in the figure indicate a line fully parallel to the RP card front panel.
Note
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
168
Installing Cards and Modules in the Chassis
Installing RP Cards in the Chassis
