Cisco ASR 9010 Installation Guide

If a fan tray is still not functioning, there could be a problem with the fan tray controller card or an
undetected problem in the fan tray cable. Replace the fan tray.
•
• If the new fan tray does not function, contact a Cisco customer service representative for assistance.
• If the Fault indicator is on, the power supply is faulty. Replace the power supply.
• If the Temp and Fault indicators are on, an overtemperature condition exists:
• Verify that the power supply fan is operating properly.
• If the fan is not operating, replace the power supply.
• Contact your Cisco representative if replacing the power supply does not fix the problem.
Cisco ASR 9000 Series Aggregation Services Router Hardware Installation Guide
220
Troubleshooting the Installation
Isolating Cooling Subsystem Problems

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
