Cisco Catalyst 3650 Series Hardware Installation Guide

1-34
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Chapter 1 Product Overview
Rear Panel
Power Supply for Catalyst 3650-8X24UQ/PD and Catalyst 3650-12X48FD/UQ/UR/UZ Switches
The Catalyst switch models and their supported power modules are shown below:
Regardless of which power supply is used, some power is drawn by the switch, and the remaining is
available for connected devices.
Table 1-16 Available PoE with Fixed Power Supply
Model Power Supply Available PoE Power
24-port PoE switch 640 W 390 W
48-port PoE switch 975 W 775 W
Table 1-17 Switch Models and Supported Power Supply Modules
Switch Model Supported Power Supply Modules
WS-C3650-8X24UQ-L/S/E PWR-C1-715WAC
PWR-C1-1100WAC (default at bay 1)
WS-C3650-8X24PD-L/S/E PWR-C1-715WAC (default at bay 1)
PWR-C1-1100WAC
WS-C3650-12X48UZ-L/S/E PWR-C1-715WAC
PWR-C1-1100WAC (default at bay 1)
WS-C3650-12X48UR-L/S/E PWR-C1-715WAC
PWR-C1-1100WAC (default at bay 1)
WS-C3650-12X48UQ-L/S/E PWR-C1-715WAC
PWR-C1-1100WAC (default at bay 1)
WS-C3650-12X48FD-L/S/E PWR-C1-715WAC
PWR-C1-1100WAC (default at bay 1)
Table 1-18 Available PoE with AC Power Supply
Model Drawn by the Switch
Available for Connected
Devices
24-port Cisco UPOE
switch
280 W Power Supply – 280-W
48-port Cisco UPOE
switch
440 W Power Supply – 440 W

Cisco Catalyst 3650 Series Specifications

General

RAM	4 GB
Flash Memory	4 GB
Ports	24 or 48 10/100/1000 Ethernet ports
Uplinks	4 x 1G SFP or 4 x 10G SFP+ (depending on model)
Stacking	Up to 9 switches with StackWise-160
Layer Support	Layer 2, Layer 3
Software	Cisco IOS Software
Power Supply	Internal power supply; optional redundant power supply available
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
