Cisco Catalyst 3650 Series Hardware Installation Guide

iii
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
CONTENTS
Preface ix
Document Conventions ix
Related Documentation x
Obtaining Documentation and Submitting a Service Request x
CHAPTER 1 Product Overview 1-1
Switch Models 1-1
Front Panel 1-10
10/100/1000 Ethernet Ports 1-15
100M/1G/2.5G/5G/10G Ethernet Ports 1-16
PoE+ and Cisco UPOE Ports 1-16
Management Ports 1-16
USB Mini-Type B Port 1-17
USB Type A Port 1-17
Uplink Ports 1-18
SFP, SFP+, and QSFP+ Modules 1-18
LEDs 1-18
SYST LED 1-20
Port LEDs and Modes 1-21
USB Console LED 1-23
ACTV LED 1-23
STACK LED 1-24
RPS LED 1-24
PoE LED 1-25
Uplink port LEDs 1-25
UID/Beacon LED 1-28
Rear Panel 1-28
RJ-45 Console Port LED 1-31
StackWise Ports 1-31
Power Supply Modules 1-32
Power Supply for Catalyst 3650-24TS/PS/TD/PD and Catalyst
3650-48TS/PS/FS/TD/PD/FD/FQ/PQ/TQ Switches
1-32
Power Supply Module for Catalyst 3650-24PDM and Catalyst 3650-48FQM Switches 1-33
Power Supply for Catalyst 3650-8X24UQ/PD and Catalyst 3650-12X48FD/UQ/UR/UZ
Switches
1-34

Cisco Catalyst 3650 Series Specifications

General

RAM	4 GB
Flash Memory	4 GB
Ports	24 or 48 10/100/1000 Ethernet ports
Uplinks	4 x 1G SFP or 4 x 10G SFP+ (depending on model)
Stacking	Up to 9 switches with StackWise-160
Layer Support	Layer 2, Layer 3
Software	Cisco IOS Software
Power Supply	Internal power supply; optional redundant power supply available
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
