Cisco Catalyst 3650 Series Hardware Installation Guide

1-10
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Chapter 1 Product Overview
Front Panel
Front Panel
This section describes the front panel components:
• 24 or 48 downlink ports of one of these types:
– 10/100/1000 ports
– 10/100/1000 PoE+ ports
– 10/100/1000 Cisco UPOE ports
– 100M/1G/2.5G/5G/10G PoE+ ports
– 100M/1G/2.5G/5G/10G Cisco UPOE ports
• Uplink ports of one of these types or combinations of:
– SFP module slots
– SFP+ module slots
– QSFP+ module slots
WS-C3650-12X48UQ-E IP Services Stackable
12 100M/1G/2.5G/5G/10G Cisco UPOE
downlink ports
36 10/100/1000 Cisco UPOE downlink ports
4 10-Gigabit SFP+ uplink ports
1100-W power supply
WS-C3650-12X48FD-E IP Services Stackable
12 100M/1G/2.5G/5G/10G Full PoE downlink
ports
36 10/100/1000 Full PoE downlink ports
2 10-Gigabit SFP+ uplink ports
1100-W power supply
WS-C3650-24PDM-E IP Services Stackable
24 10/100/1000 PoE+ downlink ports
2 1-Gigabit SFP uplink ports
2 10-Gigabit SFP+ uplink ports
Fixed 640-W power supply
WS-C3650-48FQM-E IP Services Stackable
48 10/100/1000 Full PoE downlink ports
4 10-Gigabit SFP+ uplink ports
Fixed 975-W power supply
1. PoE+ = Power over Ethernet plus (provides up to 30 W per port).
Table 1-1 Catalyst 3650 Switch Models (continued)
Switch Model Cisco IOS Image Description

Cisco Catalyst 3650 Series Specifications

General

RAM	4 GB
Flash Memory	4 GB
Ports	24 or 48 10/100/1000 Ethernet ports
Uplinks	4 x 1G SFP or 4 x 10G SFP+ (depending on model)
Stacking	Up to 9 switches with StackWise-160
Layer Support	Layer 2, Layer 3
Software	Cisco IOS Software
Power Supply	Internal power supply; optional redundant power supply available
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
