Page #83 background image
4-7
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Chapter 4 Power Supply Installation
Installing or Replacing an AC Power Supply
Do not force the power supply or fan module into a slot. This might damage the pins on the switch
if they are not aligned with the module.
A power supply that is only partially connected to the switch can disrupt the system operation.
Remove power from the power supply module before removing or installing the module.
The power supply is hot-swappable. In some configurations, such as full PoE+ or power-sharing
mode, removing a power supply causes powered devices to shut down until the power budget
matches the input power of a single power supply. To minimize network interruption, hot swap the
power supply, ensuring that the remaining supply has sufficient PoE power for all powered ports.
For information about the switch commands that display the available power budget, see the Cisco
Catalyst 3650 Series Switches Software Configuration Guides at
http://www.cisco.com/c/en/us/support/switches/catalyst-3650-series-switches/products-installation
-and-configuration-guides-list.html.
Note For information on 250-W AC power supply support on the PoE-capable switch models, see the Cisco
Catalyst 3650 Series Switches Release Notes at
http://www.cisco.com/c/en/us/support/switches/catalyst-3650-series-switches/products-release-notes-li
st.html.
Caution Do not operate the switch with one power supply module slot empty. For effective chassis cooling, both
the module slots must be populated with either a power supply or a blank cover.
Warning
Blank faceplates and cover panels serve three important functions: they prevent exposure to
hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI)
that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not
operate the system unless all cards, faceplates, front covers, and rear covers are in place.
Statement 1029
Warning
Do not reach into a vacant slot or chassis while you install or remove a module. Exposed circuitry
could constitute an energy hazard.
Statement 206
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Installing or Replacing an AC Power Supply
Step 1 Turn off the power at its source.
Step 2 Remove the power cord from the power cord retainer.
Step 3 Remove the power cord from the power connector.
Step 4 Press the release latch at the right side of the power supply module inward and slide the power supply
out (Figure 4-8).
