Cisco Catalyst 3650 Series

2-16
Catalyst 3650 Switch Hardware Installation Guide
OL-29734-01
Chapter 2 Switch Installation
Installing the StackWise Ports
Figure 2-12 Removing the StackWise Adapter Blank from a StackWise Port
Figure 2-13 Installing the StackWise Adapter in a StackWise Port
1 Torx T15 screwdriver 4 StackWise adapter blank
2 Assembly screw 5 StackWise port
3 Cisco logo 6
C
ONSOLE
M
G
M
T
347822
1
4
2
3
5
1 Torx T15 screwdriver 4 StackWise adapter
2 Assembly screw 5 StackWise port
3 Cisco logo
C
ONSOLE
M
G
M
T
347840
1
2
4
3
5
