Chapter 1 Product Overview
Front Panel
Figure 1-6 Switch Front Panel LEDs
1 STAT (status) 5
PoE
1
1. Only switches with PoE+ ports.
2 DUPLX (duplex) 6
CONSOLE (USB mini-Type B (console) port
3 SPEED 7 SYST (system)
4 STACK 8 ACTV (active)
347616
1
2
3
4
5
7
8
01X
6
