A-4
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Appendix A Specifications
Catalyst 4507R-E Switch Specifications
Altitude:
operating
nonoperating
–196 to 6561 ft (–60 to 2000 m)
–1000 to 30,000 ft (–300 to 9150 m)
Switching Components
Backplane 120 Gbps full duplex
4 Gbps Uplinks with Sup II+, Sup IV, and Sup 6-E with
TwinGig converters
8 Gbps Uplinks with Supervisor Engine V
two 10 Gbps Uplinks with Sup V-10GE and Sup 6-E
Port density 240 (max) 10/100/1000 ports
Two 10-Gbps Uplinks, and up to 30 10-Gbps ports on
switching module slots
Inline power integrated support, 820 W per line card
Physical Characteristics
Dimensions (H x W x D) 19.15 x 17.22 x 12.5 in. (49 x 44 x 32 cm)
Weight Minimum weight: 45.5 lbs (20.68 kg)
Maximum weight: 100 lbs (45.4 kg)
Chassis and backplane: 45.5 lbs (20.68 kg)
Fan tray: 6 lbs (2.7 kg)
Airflow
Switch Right to left
Power supply Front to back
Power
PoE supplied –48 VDC
Power to Modules and fans 12 VDC
Power to backplane components 3.3 VDC
Redundancy
Supervisor engine yes
Power supply 1 + 1
Table A-3 Catalyst 4507R-E Switch Specifications (continued)
Item Specification

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
