4-8
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Chapter 4 Removing and Replacing FRUs
Removing and Replacing the Power Supply
Step 13 Check the power supply and system status from the system console by entering show power command.
For more information on this command, refer to the command reference publication for your switch.
Step 14 If the LEDs or show power command output indicate a power problem or other system problem, see
Chapter 5, “Troubleshooting,” for more information.
Removing a DC-Input Power Supply
This section describes how to remove a DC-input power supply.
Required Tools
You will need the following tools to perform this procedure:
• A Phillips screwdriver
• A 10-mm wrench/socket
Removal Procedure
Warning Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Follow these steps to remove a DC-input power supply:
Step 1 Turn off the in-line power switch. (Single input only. The triple-input power supply does not have this
switch.)
Step 2 Turn off the main power switch.
Step 3 Verify that power is off to the DC circuit on the power supply you are removing.
Step 4 Loosen the screw on the terminal block cover and remove it from the terminal block (see Figure 4-11 or
Figure 4-12). The triple-input power supply has two screws on the cover.

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
