Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Chapter 1 Product Overview
Supervisor Engines
Supervisor Engines
The following supervisor engines are available for the Catalyst 4500 series and Catalyst 4500 E-series
switches:
• Supervisor Engine II-Plus (WS-X4013+) (Figure 1-5)
• Supervisor Engine II-Plus TS (WS-X4013+TS) (Figure 1-6)
• Supervisor Engine II-Plus 10GE (WS-X4013+10GE) (Figure 1-7)
Switching module
support (continued)
• 32-port 10/100-Mbps Fast Ethernet plus 2-port 1000BASE-X Layer 3
Gigabit Ethernet routing
module (WS-X4232-L3)
• 32-port 10/100-Mbps Fast Ethernet switching module with modular uplink
support (WS-X4232-RJ-XX)
– 4-port MT-RJ uplink module (WS-U4504-FX-MT) (optional)
• 2-port Gigabit Ethernet switching module (WS-X4302-GB)
• 6-port 1000BASE-X Gigabit Ethernet switching module (WS-X4306-GB)
• 6-port Gigabit Ethernet switching module (WS-X4506-GB-T)
• 18-port Gigabit Ethernet switching module (WS-X4418-GB)
• 24-port 10/100/1000B A SE -T Gigabit Ethernet sw itching m odule
(WS-X4424-GB-RJ45)
• 48-port Gigabit Ethernet 1000 BASE LX (SPF) switching module
(WS-X4448-GB-LX)
• 48-port 10/100/1000B A SE -T Gigabit Ethernet sw itching m odule
(WS-X4448-GB-RJ45)
• 24-port IEEE 802.3af-compliant PoE 10/100/1000BASE-T RJ-45 switching
module (WS-X4524-GB-RJ45V)
• 48-port 10/100/1000B A SE -T Gigabit Ethernet sw itching m odule
(WS-X4548-GB-RJ45)
• 48-port Gigabit Ethernet switching module (WS-X4448-GB-SFP)
• 48-port IEEE 802.3af compliant PoE 10/100/1000BASE-T Gigabit Ethernet
sw itching m odule (WS-X4548-GB-RJ45V)
• 6-port 10GbE X2 switching module (WS-X4606-X2-E)
• 48-port 802.3af PoE 10/100/1000 RJ45 switching module
(WS-X4648-RJ45V-E)
• 48-port Premium PoE 10/100/1000 RJ45 switching module
(WS-X4648-RJ45V+E)
1. You will need to configure the 1400 W DC input current as appropriate for the model of switch. Refer to Appendix A,
“Specifications.”
2. 1000W AC and 1300W AC power supplies will fit and function; however, power management is cautioned and only some
configurations will have adequate power. Please refer to the Cisco Power Calculator at http://tools.cisco.com/cpc/ before
configuring these power supplies.
Table 1-4 Features of the Catalyst 4510R-E Switch (continued)
Feature Description

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
