Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Appendix A Specifications
Catalyst 4507R-E Switch Specifications
Catalyst 4507R-E Switch Specifications
Table A-3 lists the Catalyst 4507R-E switch specifications.
Altitude:
operating and nonoperating –196 to 6561 ft (–60 to 2000 m)
Switching Components
Backplane 120 Gbps full duplex
Port density 240 (max) 10/100/1000 ports
Two 10-Gbps Uplinks, and up to 30 10-Gbps ports on
switching module slots
Inline power integrated support, 820 W per line card
Physical Characteristics
Dimensions (H x W x D) 17.38 x 17.31 x 12.5 in. (441.3 x 439.7 x 317.5 mm)
Weight Minimum weight: 34.5 lbs (15.6 kg)
Maximum weight: 100 lbs (45.4 kg)
Chassis and backplane = 39.5 lbs (17.95 kg)
Fan tray: 5.0 lbs (2.2 kg)
Airflow
Switch Right to left
Power supply Front to back
Power
PoE supplied –48 VDC
Power to Modules and fans 12 VDC
Power to backplane components 3.3 VDC
Redundancy
Supervisor engine no
Power supply 1 + 1
Table A-2 Catalyst 4506-E Switch Specifications (continued)
Item Specification
Ta b l e A-3 Catalyst 4507R-E Switch Specifications
Item Specification
Environmental
Temperature,
ambient operating
ambient nonoperating and storage
32 to 104°F (0 to 40°C)
–40 to 167°F (–40 to 75°C)
Humidity (RH), ambient (noncondensing):
operating
nonoperating and storage
10 to 90%
5 to 95%

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
