Appendix A Specifications
Catalyst 4500 Power Supplies
Ta b l e A-5 1000 W AC-Input Power Supply Specifications
Item Specification
Minimum software requirement Cisco IOS Release 12.1(12c)EW
Power over Ethernet Not supported
1
1. A Catalyst 4503 with a Catalyst 4500 series Supervisor Engine II-Plus TS and a 1000W pow er supply will be able to provide
158.4 W of Pow er over Ethernet to ports on the supervisor engine. Sw itching modules in other slots will not be able to provide PoE.
AC-input type Autoranging input with power factor corrector
AC-input voltage 100 to 240 VAC (±10% for full range)
AC-input current 12 A @ 100 VAC, 5 A @ 240 VAC
Maximum KVA rating 1.32 KVA
AC-input frequency 50/60 Hz (nominal) (±3 Hz for full range)
Power supply output capacity 1050 W plus 40 W (fan)
Power supply output 12 V @ 83.4 A, 3.3V @12.2 A, 1667 W maximum
Output holdup time 20 ms minimum
Max heat dissipation 943 BTUs/hr
Ta b l e A-6 1300 W AC-Input Power Supply Specifications
Item Specification
Minimum software requirement Cisco IOS Release 12.1(12c)EW
Power over Ethernet Supported, up to 800 W
(211 Cisco phones in combined mode)
AC-input type Autoranging input with power factor corrector
AC-input voltage 100 to 240 VAC (±10% for full range)
AC-input current 16 A @ 100 VAC, 7 A @ 240 VAC
AC-input frequency 50/60 Hz (nominal) (±3 Hz for full range)
Maximum KVA rating 1.76 KVA
Power supply output 1300 W maximum
1050 W+ 40 W redundant mode (Data)
1667 W maximum in combined mode (Data)
800 W maximum each in redundant mode (PoE)
1333 W maximum in combined mode (PoE)
Power supply output (AC supply) 12 V @ 84.7 A, 3.3 V @ 12.5 A (Data),
–50 V @ 16.7 A (PoE)
Max heat dissipation 1568 BTUs/hr
Output holdup time 20 ms minimum

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
