1-10
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Chapter 1 Product Overview
Switch Features
Table 1-3 describes the features of the Catalyst 4507R-E switch.
Ta b l e 1-3 Features of the Catalyst 4507R-E Switch
Feature Description
Ethernet speeds • Ethernet (10BASE-T) interface to workstations and repeaters
• Fast Ethernet (100BASE-T) interface to workstations, servers, switches, and
routers
Note Autonegotiation of link speed on each 10/100 port allows migration to
100BASE-T from a 10BASE-T installed base.
• Gigabit Ethernet (1000BASE-T and 1000BASE-X) interfaces for backbone
interconnection of high-performance switches and routers
• 10-Gigabit Ethernet interfaces for backbone interconnection of
high-performance switches and routers
Standard equipment • Seven-slot modular chassis with one slot reserved for a supervisor engine,
one slot reserved for a redundant supervisor engine, and five slots for
switching modules
• Two power supply bays
• One hot-swappable fan assembly
Power supplies • Can support a 1000 W, 1300 W, 1400 W, 2800 W, or 4200W AC-input power
supply or a 1400 W DC-input single or triple-input power supply
1
• Optional redundant power supply
Supervisor engine
support
• Supports the WS-X4013+, WS-X4515, WS-X4516, WS-X4516-10GE, and
WS-X45-Sup6-E Supervisor Engines
• Holds the ASIC-based forwarding engine (data path) and the management
processor and software (control path)
• Features interface monitoring, environmental status, and SNMP and
console/Telnet interface
Note With a single supervisor, packets are not forwarded while the module is
removed; a system reboot occurs when a supervisor engine is reinserted.
In redundant systems, removing the active supervisor causes the standby
supervisor to become active.

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
