1-30
Catalyst 4500 E-Series Switches Installation Guide
OL-13972-01
Chapter 1 Product Overview
Power Supplies
The maximum total input current is 42.5A and the maximum ambient temperature is 55 C. To determine
total maximum input power to a supply, add up the active individual module input power ratings.
Table 1-9 provides output information for these modes, given two supplies working in combined mode.
Table 1-10 provides output information for these modes, given two supplies working in redundant mode.
Note In a redundant configuration with all inputs supplied, there must be a 100 W minimum system load or
the OUTPUT FAIL LED shows a false failure.
The 1400 W DC Triple Input SP Power Supply requires a minimum draw from the system that it is
installed in.
Table 1-11 shows the minimum draw for the possible modes.
Ta b l e 1-9 Combined Mode Power Supply Configuration
(2450 W Max Output Power)
Input
Number
Maximum Input Current
Maximum Input
Power @ –44 V DC
1 12.5 A @ –44 V DC 550 W
2 15 A @ –44 V DC 660 W
3 15 A @ –44 V DC 660 W
Ta b l e 1-10 Dual Redundant Mode Power Supply Configuration
(1400 W Max Output Power)
Input
Number
Approximate
Input Current
Approximate Input
Power @ –40.5 V DC
Approximate Input
Power @ –44 V DC
1 6.25 A @
–40.5 / –44 V DC
253 W 275 W
2 7.5 A @ –40.5 /
–44 V DC
304 W 330 W
3 7.5 A @ –40.5 /
–44 V DC
304 W 330 W
Ta b l e 1-11 Minimum Load Table
PSU1 PSU2
Input 1 Input 2 Input 3 Input 1 Input 2 Input 3
12V
Minimum
Load
3.3V
Minimum
Load
Single Operation
Mode 1 ON OFF OFF – – – 1.33A 0.6A
Mode 2 OFF ON OFF – – – 1.33A 0.6A
OFF OFF ON – – – 1.33A 0.6A
Mode 3 ON ON OFF – – – 2.66A 0.6A
ON OFF ON – – – 2.66A 0.6A
Mode 4 OFF ON ON – – – 2.66A 0.6A

Cisco Catalyst 4500e Series Specifications

General

Series	Catalyst 4500E Series
Stackable	No
Chassis Options	3-slot, 6-slot, 7-slot, 10-slot
Power Supply Options	AC, DC
Redundancy	Power supply redundancy, supervisor engine redundancy (1+1)
Layer Support	Layer 2
Virtualization	Yes (Virtual Switching System - VSS)
Form Factor	Modular
Ports	Gigabit Ethernet, 10 Gigabit Ethernet, 40 Gigabit Ethernet, and 100 Gigabit Ethernet options depending on the line cards
Jumbo Frame Support	Yes
Features	Flexible NetFlow, TrustSec
Maximum Port Density	Up to 384 ports per chassis
Operating System	Cisco IOS XE
Management	CLI, SNMP, Cisco Prime Infrastructure, Cisco DNA Center
Security Features	802.1X
VLAN Support	Up to 4096 VLANs
QoS Support	Yes
Supervisor Engine Options	Sup8-E
