Mod Sub-Module Model Serial Hw Status
---- --------------------------- ------------------ ----------- ------- -------
1 Distributed Forwarding Card WS-F6K-DFC4-EXL SAL1532M1VE 1.0 Ok
3 Policy Feature Card 4 VS-F6K-PFC4XL SAD1422005E 0.509 Ok
3 CPU Daughterboard VS-F6K-MSFC5 SAL17142D69 2.0 Ok
4 Policy Feature Card 4 VS-F6K-PFC4XL SAD142502KP 0.509 Ok
4 CPU Daughterboard VS-F6K-MSFC5 SAL171424F1 2.0 Ok
5/0 NAM Application Processor SVC-APP-PROC-1 SAL161065NJ 1.0 Ok
6 Distributed Forwarding Card WS-F6K-DFC4-AXL SAL1736CC7W 0.1 Ok
Base PID:
Mod Model Serial No.
---- ----------- ----------
5 WS-SVC-APP-HW-1 SAL16127XFD
Mod Online Diag Status
---- -------------------
1 Pass
2 Pass
3 Pass
4 Pass
5 Not Applicable
5/0 Not Applicable
6 Pass
Switch#show module switch 1 slot 6
Switch Number: 1 Role: Virtual Switch Standby
---------------------- -----------------------------
Mod Ports Card Type Model Serial No.
--- ----- -------------------------------------- ------------------ -----------
6 48 DCEF-XL 48P 10/100/1000MB Ethernet C6800-48P-TX-XL SAL1736CC7W
Mod MAC addresses Hw Fw Sw Status
--- ---------------------------------- ------ ------------ ------------ -------
6 7c69.f69b.c8d8 to 7c69.f69b.c907 0.1 12.2(18r)S1 15.1(2)SY2 Ok
Mod Sub-Module Model Serial Hw Status
---- --------------------------- ------------------ ----------- ------- -------
6 Distributed Forwarding Card WS-F6K-DFC4-AXL SAL1736CC7W 0.1 Ok
Mod Online Diag Status
---- -------------------
6 Pass
Related Topics
Installing an Ethernet Switching Module, on page 25
C6800-48P-TX and C6800-48P-TX-XL Ethernet Modules, on page 1
Example: show module Command Output for C6800-48P-SFP
These are examples of the show module command output for the C6800-48P-SFP Ethernet module:
Switch# show module sw 2
Switch Number: 2 Role: Virtual Switch Active
---------------------- -----------------------------
Mod Ports Card Type Model Serial No.
--- ----- -------------------------------------- ------------------ -----------
1 20 DCEF2T 4 port 40GE / 16 port 10GE WS-X6904-40G SAL1627FUGE
3 5 Supervisor Engine 2T 10GE w/ CTS (Acti VS-SUP2T-10G SAL17152N0N
4 5 Supervisor Engine 2T 10GE w/ CTS (CSSO VS-SUP2T-10G SAL17152F4G
7 48 DCEF 48P 1GE SFP C6800-48P-SFP SAL1810N5E2
Mod MAC addresses Hw Fw Sw Status
--- ---------------------------------- ------ ------------ ------------ -------
1 1cdf.0f9b.e9fa to 1cdf.0f9b.ea0d 1.0 12.2(50r)SYL 15.1(2)SY2 Ok
Catalyst 6800 Ethernet Module Installation Guide
35
Installing and Removing Modules, Transceivers, and Attaching Cables
Example: show module Command Output for C6800-48P-SFP
