Cisco Catalyst 6800 User Manual

CHAPTER 1
Ethernet Switching Modules Overview
•
10/100/1000 Copper Ethernet Modules, page 1
•
1-Gigabit Pluggable Ethernet Modules, page 4
•
10-Gigabit Pluggable Ethernet Modules, page 6
10/100/1000 Copper Ethernet Modules
C6800-48P-TX and C6800-48P-TX-XL Ethernet Modules
C6800-48P-TX and C6800-48P-TX-XL Ethernet modules provide 48 10/100/1000-Mbps full- or half-duplex
ports.
Figure 1: C6800-48P-TX and C6800-48P-TX-XL Ethernet Module Front Panel
Even numbered ports3Status LED1
RFID4Odd numbered ports2
The sticker on the module faceplate identifies it as either a C6800-48P-TX or a C6800-48P-TX-XL depending
on whether a WS-F6K-DFC4-A or WS-F6K-DFC4-AXL daughter card is installed on the module.
Catalyst 6800 Ethernet Module Installation Guide
1

Cisco Catalyst 6800 Specifications

General

Brand	Cisco
Model	Catalyst 6800
Category	Server
Language	English
