Table 14: Power and Heat Values
DC Heat
Diss.
(BTU/HR)
DC-Input
Power
(Watts)
AC Heat
Diss.
(BTU/HR)
AC-Input
Power
(Watts)
Module
Power
(Watts)
Module
Current
(Amps)
6
Switch Model + DFC Card
——
1218.133573576.86Cisco Catalyst 6807-XL
Switch
These values apply to the
C6800-8P10G (comes
installed with
WS-F6K-DFC4-E) and
the C6800-8P10G-XL
(comes installed with
WS-F6K-DFC4-EXL)
modules
1218.133571218.133573578.5Cisco Catalyst 6500-E
Series Switch
These values apply to the
C6800-8P10G (comes
installed with
WS-F6K-DFC4-E) and
the C6800-8P10G-XL
(comes installed with
WS-F6K-DFC4-EXL)
modules
6
On a Cisco Catalyst 6807-XL switch, module current is @ 52V.
On a Cisco Catalyst 6503-E and 6504-E module current is @50V; On all other Cisco Catalyst 6500-E Series switches, module
current is @ 42V.
Related Topics
Installing an Ethernet Switching Module, on page 25
C6800-8P10G and C6800-8P10G-XL Ethernet Modules, on page 6
C6800-16P10G and C6800-16P10G-XL Module Specifications
The following table lists the physical specifications of the modules:
Table 15: Physical Specifications
SpecificationItem
1.73 x 15.4 x 16.4 inches (4.39 x 39.11 x 41.65 cm)Dimensions (H x W x D)
11.02 lb (5.0 kg)Weight
Catalyst 6800 Ethernet Module Installation Guide
41
Module Specifications
C6800-16P10G and C6800-16P10G-XL Module Specifications
