The following table lists the environmental specifications of the modules:
Table 16: Environmental Specifications
SpecificationItem
Certified for operation: 32° to 104°F (0° to 40°C)
Designed and tested for operation: 32° to 130°F (0° to 55°C)
Operating temperature
10 to 90 percentHumidity (RH) ambient (noncondensing)
Certified for operation: 0 to 6500 ft (0 to 2000 m)
Designed and tested for operation: -200 to 10,000 ft (-60 to
3000 m)
Operating altitude
Table 17: Power and Heat Values
DC Heat
Diss.
(BTU/HR)
DC-Input
Power
(Watts)
AC Heat
Diss.
(BTU/HR)
AC-Input
Power
(Watts)
Module
Power
(Watts)
Module
Current
(Amps)
7
Switch Model + DFC Card
——
1218.133573576.86Cisco Catalyst 6807-XL
Switch
These values apply to the
C6800-16P10G (comes
installed with
WS-F6K-DFC4-E) and
the C6800-16P10G-XL
(comes installed with
WS-F6K-DFC4-EXL)
modules
1218.133571218.133573578.5Cisco Catalyst 6500-E
Series Switch
These values apply to the
C6800-16P10G (comes
installed with
WS-F6K-DFC4-E) and
the C6800-16P10G-XL
(comes installed with
WS-F6K-DFC4-EXL)
modules
7
On a Cisco Catalyst 6807-XL switch, module current is @ 52V.
On a Cisco Catalyst 6503-E and 6504-E module current is @50V; On all other Cisco Catalyst 6500-E Series switches, module
current is @ 42V.
Catalyst 6800 Ethernet Module Installation Guide
42
Module Specifications
C6800-16P10G and C6800-16P10G-XL Module Specifications

Cisco Catalyst 6800 Specifications
