Table 21: Module Front Panel - Status LED Colors and Meaning
MeaningLED Color
All diagnostics pass; the module is operational.Green
The module is booting or running diagnostics; an overtemperature condition
has occurred.
Orange
Table 22: Module Front Panel - ID LED Color and Meaning
MeaningLED Color
Identifies the Ethernet module in the chassis. You can turn this LED on and
off using CLI commands. Turning the beacon on helps to identify the module
to servicing personnel.
Blue
Table 23: Module Front Panel - Port Link LED Colors and Meaning
MeaningLED Color
The port is active (the link is connected and operational).Green
The port failed diagnostics and is disabled.Flashing orange
The port is disabled.Orange
The module is resetting; an overtemperature condition has occurred.Red
Related Topics
Installing an Ethernet Switching Module, on page 25
C6800-48P-TX and C6800-48P-TX-XL Ethernet Modules, on page 1
Installing an Ethernet Switching Module, on page 25
C6800-48P-SFP and C6800-48P-SFP-XL Ethernet Modules, on page 4
Installing an Ethernet Switching Module, on page 25
C6800-8P10G and C6800-8P10G-XL Ethernet Modules, on page 6
Installing an Ethernet Switching Module, on page 25
C6800-16P10G and C6800-16P10G-XL Ethernet Modules, on page 10
Installing an Ethernet Switching Module, on page 25
C6800-32P10G and C6800-32P10G-XL Ethernet Modules, on page 13
Catalyst 6800 Ethernet Module Installation Guide
46
LEDs
Ethernet Module LEDs
