1.58 X 3.25 X 12.20 in. (40.1 X 82.55 X 309.9 mm)PWR-C1-715WAC
1.58 X 3.25 X 12.20 in. (40.1 X 82.55 X 309.9 mm)PWR-C1-350WAC
1.58 X 3.25 X 13.7 in. (40.1 X 82.55 X 348.2 mm)PWR-C1-1900WAC-P
1.58 X 3.25 X 13.7 in. (40.1 X 82.55 X 348.2 mm)PWR-C1-1100WAC-P
1.58 X 3.25 X 12.20 in. (40.1 X 82.55 X 309.9 mm)PWR-C1-715WAC-P
1.58 X 3.25 X 12.20 in. (40.1 X 82.55 X 309.9 mm)PWR-C1-350WAC-P
1.58 X 3.25 X 12.20 in. (40.1 X 82.55 X 309.9 mm)PWR-C1-715WDC
1.58 x 4.0 x 7.6 in. (40.1 X 101.6 X 193 mm)PWR-C6-600WAC
1.58 x 4.0 x 7.6 in. (40.1 X 101.6 X 193 mm)PWR-C6-1KWAC
Specifications for the Power Supplies, Switches, and Fan
Table 41: Power Specifications for Platinum Rated AC Power Supplies
Power SupplySpecification
PWR-C1-350WAC-PPWR-C1-715WAC-PPWR-C1-1100WAC-PPWR-C1-1900WAC-P
350 W
715 W1100 W1500 W with
115 V
1900 W with
230 V
Maximum
output power
350 W, 100 to
240 VAC
(autoranging),
50-60 Hz
715 W, 100 to
240 VAC
(autoranging),
50-60 Hz
1100 W, 115 to
240 VAC
(autoranging),
50-60 Hz
1500 W, 115 V
to 127 VAC
(autoranging),
50-60 Hz
1900 W, 200 V
to 240 VAC
(autoranging),
55-60 Hz
Input voltage
and frequency
4–2 A10–5 A12-6 Amaximum of 16
A
maximum of 12
A
Input current
–56 V@6.25 A–56 V@12.8 A–56 V@19.64 A-56 V@26.78 A-56 V@33.92 AOutput ratings
1348 BTUs per
hour, 395 W
2723 BTUs per
hour, 798 W
4147 BTUs per
hour, 1215 W
5565 BTUs per
hour, 1631 W
6899 BTUs per
hour, 2022 W
Total input
BTU
5
1194 BTUs per
hour, 350 W
2440 BTUs per
hour, 715 W
3754 BTUs per
hour, 1100 W
5118 BTU per
hour, with 115 V
6483 BTU per
hour, with 230 V
Total output
BTU
5
The total input and total output BTU ratings refer to input power to the power supply and output power
to the switch. The BTU ratings are based on 100 VAC for the 350 W and 715 W power supplies and
115 VAC for the 1100 W power supply.
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
116
Technical Specifications
Specifications for the Power Supplies, Switches, and Fan
