Cisco Catalyst 9300X User Manual

Identifying a Crossover Cable
To identify a crossover cable, compare the two modular ends of the cable. Hold the cable ends side-by-side,
with the tab at the back. The wire connected to the pin on the outside of the left plug should be a different
color from the wire connected to the pin on the inside of the right plug.
Figure 78: Identifying a Crossover Cable
Console Port Adapter Pinouts
The RS-232 console port uses an 8-pin RJ-45 connector. Use an RJ-45-to-DB-9 adapter cable to connect the
switch console port to a console PC. You need to provide a RJ-45-to-DB-25 female DTE adapter to connect
the switch console port to a terminal.
Table 52: Console Port Signaling with a DB-9 Adapter
Console
Device
RJ-45-to-DB-9
Terminal Adapter
Switch Console
Port (DTE)
SignalDB-9 PinSignal
RxD2TxD
GND5GND
GND5GND
TxD3RxD
Table 53: Console Port Signaling with a DB-25 Adapter
Console
Device
RJ-45-to-DB-25
Terminal Adapter
Switch Console
Port (DTE)
SignalDB-25 PinSignal
RxD3TxD
GND7GND
GND7GND
TxD2RxD
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
127
Connector and Cable Specifications
Console Port Adapter Pinouts

Cisco Catalyst 9300X Specifications

General

Category	Switch
Total number of MAC addresses	64, 000
Total number of IPv4 routes	32, 000
Total number of IPv6 routes	16, 000
Jumbo frames	9198 bytes
DRAM	8 GB
Flash	16 GB
Model	Cisco Catalyst 9300X
Number of VLANs	4, 094
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	5 to 90% relative humidity
