DescriptionColor
There is a fault: load shedding is occurring, a StackPower cable is defective, or an
administrative action is required. See the switch software configuration guide for
information about configuring StackPower.
Amber
The StackPower budget is not sufficient to meet current power demands.Blinking amber
Port LEDs and Modes
Each Ethernet port, 1-Gigabit Ethernet module slot, and 10-Gigabit Ethernet module slot has a port LED.
These port LEDs, as a group or individually, display information about the switch and about the individual
ports. The port mode determines the type of information shown by the port LEDs.
To select or change a mode, press the Mode button until the desired mode is highlighted. When you change
port modes, the meanings of the port LED colors also change.
When you press the Mode button on any switch in the switch stack, all the stack switches change to show the
same selected mode. For example, if you press the Mode button on the active switch to show the SPEED
LED, all the other switches in the stack also show the SPEED LED.
Table 12: Port Mode LEDs
DescriptionPort ModeMode LED
The port status. This is the default mode.Port statusSTAT
The port operating speed: 10, 100, or 1000 Mb/s.Port speedSPEED
The port duplex mode: full duplex or half duplex.Port duplex modeDUPLX
The active switch status.ActiveACTV
Stack member status.
The StackWise port status. See STACK LED, on page 16.
Stack member status
StackWise port status
STACK
The PoE+ port status.The PoE+ port status.PoE
1
1
Only switches with PoE+ ports.
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
18
Product Overview
Port LEDs and Modes
