To remove a StackWise-320 adapter from the connector, make sure you press down the spring latch to unlock
it from the slot.
Removing and installing the StackWise cable can shorten its useful life. Do not remove and insert the cable
more often than is absolutely necessary (installing and removing it up to 200 times is supported).
Step 5 Connect the other end of the cable to the StackWise port on the other switch.
Connecting a StackWise-480/1T Cable
Procedure
Step 1 Remove the dust covers from the StackWise cables and store them for future use.
Step 2 Connect the cable to the StackWise port on the switch rear panel. Align the connector and connect the StackWise
cable to the StackWise port on the switch rear panel and finger-tighten the screws (clockwise direction). Make
sure the Cisco logo is on the top side of the connector as shown in the figure.
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
62
Installing a Switch
Connecting a StackWise-480/1T Cable

Cisco Catalyst 9300X Specifications

General

Category	Switch
Total number of MAC addresses	64, 000
Total number of IPv4 routes	32, 000
Total number of IPv6 routes	16, 000
Jumbo frames	9198 bytes
DRAM	8 GB
Flash	16 GB
Model	Cisco Catalyst 9300X
Number of VLANs	4, 094
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	5 to 90% relative humidity
