The switch generates logs when you insert or remove a network module with SFP/SFP+/SFP28/QSFP+ slots.
Note
Use only supported network modules and Cisco pluggable transceivers. Each module has an internal serial
EEPROM that is encoded with security information.
The network module is hot-swappable. If you remove a module, replace it with another network module or
a blank module.
The switch complies with EMC, safety, and thermal specifications when a network module is present. If no
uplink ports are required, install a blank network module.
Note
Before you begin
When installing network modules, observe these precautions:
• Do not remove the blank module from the slot unless you are installing a network module. A module
must be in the uplink slot at all times.
• Do not remove the dust plugs from the pluggable transceivers or the rubber caps from the fiber-optic
cable until you connect the cable. The plugs and caps protect the module ports and cables from
contamination and ambient light.
• Removing and installing a network module can shorten its useful life. Do not remove and insert a network
module more often than is necessary.
• To prevent ESD damage, follow your normal board and component handling procedures when connecting
cables to the switch and other devices.
Unlike other network modules, the C9300-NM-8X cannot be fully inserted and secured until the jackscrew
is properly tightened.
1. Push the module into the uplink slot until the jackscrew connects with the rightmost tab.
2. You will feel some light resistance, because a spring-loaded tab inside the slot will push back against the
C9300-NM-8X module
3. Continue to tighten the jackscrew while gently pushing the front panel of the network module into the
slot.
Note
Procedure
Step 1 Attach an ESD-preventive wrist strap to your wrist and to an earth ground surface.
Step 2 Remove the module from the protective packaging.
Step 3 Remove the blank module from the switch and save it.
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
69
Installing a Network Module
Installing a Network Module

Cisco Catalyst 9300X Specifications

General

Category	Switch
Total number of MAC addresses	64, 000
Total number of IPv4 routes	32, 000
Total number of IPv6 routes	16, 000
Jumbo frames	9198 bytes
DRAM	8 GB
Flash	16 GB
Model	Cisco Catalyst 9300X
Number of VLANs	4, 094
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	5 to 90% relative humidity
