Figure 33: Flexible Retainer Strip
Flexible retainer strip3The end that is fixed to the power supply
module
1
--Direction in which to push the retainer strip
latch, to loosen or remove the strip from the
power cord (away from the retainer strip that
is behind it)
2
The following figure shows how the flexible retainer strip inserts into the clamp hole.
The illustration does not include the chassis, for the sake of clarity.
Note
Cisco Catalyst 9400 Series Switches Hardware Installation Guide
102
Removing and Replacing FRUs
Power Cord Retainer Mechanism
