Connecting a Power Injector
The AP supports the following power injectors:
Table 11: Supporting Power Injectors
DescriptionPower Source
60W rated outdoor power injector, with North
America AC plug
AIR-PWRINJ-60RGD1=
60W rated outdoor power injector, global version
without AC plug
AIR-PWRINJ-60RGD2=
60W rated outdoor power injector, 5GEIW-PWRINJ-60RGDMG=
The power injector provides DC voltage to the AP over the Ethernet cable and supports a total end-to-end
Ethernet cable length of 100 m (328 ft) from the switch to the AP.
When an optional power injector powers your AP, follow these steps to complete the installation:
Step 1 Before applying PoE to the AP, ensure that the AP is grounded (see Grounding the Access Point, on page 34).
Step 2 Connect a CAT5e or better Ethernet cable from your wired LAN network to the power injector.
To reduce the risk of fire, use only No. 24 AWG or larger telecommunication line cord. Statement 1023
Warning
The installer is responsible for ensuring that powering the AP from this type of power injector is allowed by
local and/or national safety and telecommunications equipment standards.
Note
Step 3 Ensure that the antennas are connected, and that ground is attached to the AP before you apply power to the AP.
Step 4 Connect a shielded outdoor-rated Ethernet (CAT5e or better) cable between the power injector and the AP's PoE-in
connector.
Step 5 Connect the Ethernet cable to the AP PoE-In port.
Connecting to the DC Power Port Using Cable Gland
Follow these steps to connect to the DC power port using cable gland:
