Cisco Catalyst IW9167E - 4-Pin Micro-Fit Connector for DC Power; M12-RJ45 Adapter

4-Pin Micro-Fit Connector for DC Power
The following figures show the 4-pin Micro-Fit connector for DC power.
Figure 2: Mating Connector: Molex Micro-Fit 43025-0400
Figure 3: Mating Connector Front View
AssignmentMolex Micro-Fit Pin
Black ( - Negative Terminal)Pin 1
Not assignedPin 2
White (+ Positive Terminal)Pin 3
Not assignedPin 4
M12-RJ45 Adapter
M12-RJ45 adapter (Cisco PID: IW-ACC-M12ETH=) can be used to support M12 X-coded connector.
