MeaningColorLED Message Type
SNR Excellent (>=25)Blinking Green
Link Quality/SNR
Indicator
SNR Good (15<=x<25)Fade-in Green
SNR Poor (10<=x<15)Fade-in Amber
SNR Unbearable (<10)Fade-in Red
This is a general warning of insufficient inline power.
Cycling through Red, Green,
and Amber
Operating Status
In the state of requesting IP address from DHCP server.Chirping (short blips) AmberLimbo
(Provisioning)
mode: Fallback
This status indicates that the IP address is retrieved
from DHCP server.
AmberLimbo
(Provisioning)
mode: DHCP
